CAMERA COLOR IP BULLET TC-C34QN:I5W/WIFI/2.8MM/V4.0 TIANDY

Description

PRODUCT DETAILS OF CAMERA COLOR IP BULLET TC-C34QN:I5W/WIFI/2.8MM/V4.0 TIANDY Product Type: Color IP Bullet Camera Model: TC-C34QN: I5W/WIFI/2.8MM/V4.0 Brand: Tiandy Resolution: 5MP Lens: 2.8mm Connectivity: Wi-Fi Compression: H.264/H.265 Mount: Bullet, designed for wall mounting Weatherproof Rating: IP67, suitable for outdoor use Power: Powered by Wi-Fi (no wired connection needed) Storage: Supports SD card storage or NVR Audio: No built-in audio Night Vision: Infrared (IR) for clear night-time footage Motion Detection: Yes, with motion-triggered alerts Features: Supports remote viewing via mobile app

Key Features

Metal+plastic housing ·Up to 4MP,2560×1440@20fps ·S+265/H.265/H.264B/H.264M/H.264H ·Color:0.02Lux@(F2.0,AGC ON),B/W:0Lux with IR ·IR range up to 50m ·Built-in Mic, Built-in Speaker ·Support microSD/microSDHC/microSDXC card,up to 512GB ·Operating conditions -30℃~60℃(-22℉~140℉), ≤95%RH ·DC12V±25%,Max. 7.5W ·IP67

Specifications

Camera Image Sensor 1/2.8″CMOS Min. Illumination Color:0.02Lux@(F2.0,AGC ON),B/W:0Lux with IR Shutter Time 1s~1/100000s Day&Night IR-cut filter with auto switch (ICR) Smart IR Yes WDR DWDR S/N >40dB Angle Adjustment 0~360°(P); 0~80°(T); 0~360°(R) Lens Lens Type Fixed focal lens Focal Length 2.8mm Lens Mount M12 Aperture Range F1.6 Aperture Type Fixed Field of View 101.3°(H); 56.8°(V); 113.9°(D) DORI Distance Detect:45.71m Observe:18.14m Recognize:9.14m Identify:4.57m Illuminator IR LEDs 2 IR Distance Up to 50m Wavelength 850nm White LEDs 2 Whitelight Distance 15m Compression Standard Video Compression S+265/H.265/H.264B/H.264M/H.264H Video Bit Rate 32k~4Mbps Audio Compression G.711A/G.711U Audio Sampling Rate 8kHz/16kHz Image Max. Resolution 4MP,2560×1440@20fps Main Stream PAL:20fps(2560×1440, 2304×1296, 1920×1080, 1280×720, 704×576, 640×480) NTSC:20fps(2560×1440, 2304×1296, 1920×1080, 1280×720, 704×576, 640×480) Sub Stream PAL:20fps(704×576, 704×288, 352×288, 640×360) NTSC:20fps(704×480, 704×240, 352×240, 640×360) BLC Yes HLC Yes AGC Yes 3D DNR Yes White Balance Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance OSD Overlay of additional characters in 1 regions, 1 line, with a maximum of 48 characters or 16 Chinese characters per region; 16*16/32*32/48*48/64*64 Privacy Mask 4 black static areas Defog Yes Feature Exceptions Alarm Voltage Alarm; Disk Full; Disk R/W Error; IP Address Conflict Linkage Method Trigger Sound; Trigger Recording; Trigger Capture; Notify Surveillance Center; Alarm Output Network ANR Yes Protocols HTTP; TCP/IP; UDP; ICMP; DHCP; DNS; NTP; TLS v1.2; IPv4; SSH; Unicast; FTP System Compatibility ONVIF(Profile S/T) ; SDK; CGI; RTSP Remote Connection ≤2 Client Easy7 VMS Moblie Client EasyLive Plus Web IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+ Wi-Fi Transmission Distance Up tp 50m( based on actual environment) Wireless Standard IEEE802.11b/ 802.11g/802.11n Frequency Range 2.4 GHz ~ 2.4835 GHz Channel Bandwidth 20/40MHz Wi-Fi Security WPA-PSK/WPA2-PSK Interface Communication Interface 1*RJ-45 (10/100 Base-T) Built-in Mic Yes Built-in Speaker Yes Reset Button Yes On-board Storage Support microSD/microSDHC/microSDXC card,up to 512GB General Web Client Language 3 languages Simple Chinese/English/Vietnamese Operating Temperature -30℃~60℃(-22℉~140℉) Operating Humidity ≤95%RH Storage Temperature -30℃~60℃(-22℉~140℉) Storage Humidity 10%~95%RH(non-condensing) Power Supply DC12V±25%,Max. 7.5W Protection Surge4000V; ESD6000V; IP67 Boundary Dimensions 164(L)73(W)73(H)mm Package Dimensions 215(L)95(W)120(H)mm GrossWeight 0.46kg
